XGN15-12 AC Metal-Enclosed Ring Network Switchgear
Product Features
- New generation metal-enclosed switchgear
• Uses SF6 switches as the main switch
• Air insulation for the whole cabinet
• Suitable for power distribution automation
• Both compact and expandable
• Simple structure and flexible operation
• Reliable interlocking
• Easy installation
• Sensor technology and latest protection relays
• Advanced technical performance
• Lightweight and flexible assembly solution
• IP rating: IP2X
XGN15-12 AC Metal-Enclosed Ring Network Switchgear
Type Meaning (Model Code)
X G N 15 – 12
X: Box type
G: Fixed type
N: Indoor
15: Design serial number
12: Rated voltage (kV)
Example: XGN15-12 means Box type, Fixed installation, Indoor, Design serial number 15, 12kV rated voltage.
Product Overview
The XGN15-12 series unitized, modular SF6 AC metal-enclosed ring network switchgear is a new generation of metal-enclosed switchgear that uses SF6 switches as the main switch and air insulation for the whole cabinet. It is suitable for power distribution automation, is both compact and expandable, and features simple structure, flexible operation, reliable interlocking, and easy installation. It offers satisfactory technical solutions for various applications and user requirements.
By utilizing sensor technology and the latest protection relays, together with advanced technical performance and a lightweight and flexible assembly solution, it can meet the ever-changing demands of the market.
The XGN15-12 series unitized SF6 ring network cabinet is applicable to the power systems with an AC frequency of 50Hz and a voltage of 12kV, and is widely used in industrial and civil cable ring networks and power supply terminal projects. It is especially suitable for the following places: special places that require automatic switching of dual power supplies, power distribution in urban residential areas, small secondary substations, switching stations, industrial and mining enterprises, shopping malls, airports, subways, wind power plants, hospitals, stadiums, railways, tunnels, etc.
The IP rating is IP2X.
Product Features
- New generation metal-enclosed switchgear
• Uses SF6 switches as the main switch
• Air insulation for the whole cabinet
• Suitable for power distribution automation
• Both compact and expandable
• Simple structure and flexible operation
• Reliable interlocking
• Easy installation
• Sensor technology and latest protection relays
• Advanced technical performance
• Lightweight and flexible assembly solution
• IP rating: IP2X
Structural Features
The cabinet shell of the XGN15-12 type ring network switchgear is formed by CNC machining of aluminum-zinc-coated plates, galvanized plates or cold-rolled plates, and the panel is treated by plastic spraying. The switchgear consists of four isolated compartments: busbar chamber, switch body, cable chamber, operating mechanism and control chamber. A pressure relief channel is set at the rear of the cabinet. The cabinet body has a reasonable structure, is compact and applicable, has a small volume, and features convenient and flexible operation, perfect and reliable five-prevention interlocking, simple and convenient installation, safe and stable operation, and expandability.
Additional information
| Product Series | XGN15-12 AC Metal-Enclosed Ring Network Switchgear |
|---|---|
| Application | special places that require automatic switching of dual power supplies, power distribution in urban residential areas, small secondary substations, switching stations, industrial and mining enterprises, shopping malls, airports, subways, wind power plants, hospitals, stadiums, railways, tunnels, etc. |
| IP rating | IP2X |
